Nuron

SF 30M-22 Magnetic drill press

Cordl. magnetic drill SF 30M-22 case #2250798

Configurator
Technical Data
Documents
Features & Applications
Related Products
L601676 (4381881)
L601708 (4381901)
L601711 (4348615)
L156367_cropped (4403938)
L156419_cropped (4403940)

Powerful and cordless mag drill with permanent magnet, for drilling up to 35mm | 1-3/8" diameter holes in steel (Nuron battery platform)

  • Chuck type: Quick release 3/4" Weldon
  • Maximum torque (soft/hard joint): 45 Nm (soft joint)
  • No load RPM: gear 1: 200 rpm; gear 2: 280 rpm; gear 3: 350 rpm; gear 4: 420 rpm; gear 5: 470 rpm; gear 6: 520 rpm

Customise your kit

Tool body
Tool body with case
How many kits do you want to order?
You can not see your company prices

Please Log in or register to see your company prices.

Discounted net
£1,583.01

Technical Data

Chuck type
Quick release 3/4" Weldon
Maximum torque (soft/hard joint)
45 Nm (soft joint)
No load RPM
gear 1: 200 rpm; gear 2: 280 rpm; gear 3: 350 rpm; gear 4: 420 rpm; gear 5: 470 rpm; gear 6: 520 rpm
Dimensions (LxWxH)
315 x 120 x 460 mm
Tool body weight
12.9 kg
Rated voltage
22 V

Documents

pdf Operating Instruction SF 30M-22 (01), Arabic, Czech, Danish, English, Estonian, Finnish, Japanese, Korean, Lithuanian, Latvian, Norwegian, Russian, Swedish, Turkish, Chinese [ 5.3 MB ]

Features & Applications

Features

  • Permanent magnet – the mechanically activated magnet operates independently from the battery, helping hold the tool securely in place and protect against tool drops
  • Durable control panel – the easy-to-use control panel is made from a single piece of silicone, helping avoid chip collection to protect against repairs and tool failure
  • Longer lasting battery – our B 22-290 Nuron battery allows you to drill up to 90 holes per charge (20mm diameter in 12mm thick S235 steel)
  • Ergonomic design – built with a robust transport handle and battery garage for drop-protection, improving portability and durability
  • High-performance – the powerful brushless motor produces variable 6 speed drilling and a reverse drilling mode ideal for thread tapping

Applications

  • Core drilling with annular cutters up to a diameter of 35 mm and a thickness of 50mm
  • Thread tapping with a diameter up to M14
  • Countersinking with a diameter up to 31 mm
  • Drilling with twist drill bits with a diameter up to 18 mm
  • Reaming with a diameter up to 18 mm
