DSH 900-X Gas cut-off saw (400 mm)

Hand-held gas saw DSH 900-X 40 #2357946

Configurator
Technical Data
Documents
Features & Applications
Related Products
L600096 (3025172)
L150645_cropped (3698391)
L150688_cropped (3698402)
L150697_cropped (3698403)
L150727_cropped (3698420)

Powerful rear-handle gas saw (87cc) with auto-choke, for cutting up to 150 mm with 400 mm blades in concrete, masonry and metal

  • Rated power: 4.2 kW
  • Wet or dry operation: Wet and dry
  • Dimensions (LxWxH): 856 x 261 x 466 mm

Choose options

Pack size
  • 1 pc
 Product options
Quantity
Packs
Total Pieces
1
You can not see your company prices

Please Log in or register to see your company prices.

Discounted net
£1,980.00
£1,980.00 / 1 Piece

Technical Data

Rated power
4.2 kW
Wet or dry operation
Wet and dry
Dimensions (LxWxH)
856 x 261 x 466 mm
Fuel mixture
50:1 (2% oil)
A-weighted emission sound pressure level
100 dB (A) 1
Disc diameter
400 mm
Cutting depth
150 mm
Triaxial vibration value for cutting concrete slab (ah)
5.2 m/s² 2
  1. According to the applicable product standard (see the Operating Instruction for more details)
  2. According to the applicable product standard (see Operating Instruction for more details)

Documents

pdf Operating Instruction DSH 700-X (04); DSH 900-X (04), Arabic, Bulgarian, cn, Czech, Danish, German, Greek, English, Spanish, Estonian, Finnish, French, Hebrew, Croatian, Hungarian, Italian, Japanese, Kazakh, Korean, Lithuanian, Latvian, Dutch, Norwegian, Polish, Portuguese, Romanian, Russian, Slovak, Slovenian, Swedish, Turkish, Ukrainian, Chinese, Serbian [ 19.5 MB ]

Features & Applications

Features

  • Our most powerful gas cut-off saw – now with up to 30% lower emissions and 10% less fuel consumption, engineered to make your most demanding cutting work quicker and easier
  • Easy-start gas saw – unique auto-choke helps to make first-pull ignition the norm and flooded engines virtually impossible
  • Durable build – reinforced metal blade guard with integrated water bow and belt cover with integrated wear ribs, for reduced maintenance and longer tool lifespans
  • Easier, self-service maintenance – pre-tensioned belt and virtually unbreakable starter rope help to minimise the saw's maintenance downtime
  • Compatible accessories – combine with optional DSH-FSC floor trolley and with the DSH-P water pump to feed water to your gas saw from any source, no pressurisation needed

Applications

  • Road construction: perimeter cutting in asphalt and concrete
  • Sewage work: cutting metal, concrete and plastic pipes
  • Floor construction: cutting expansion joints in fresh concrete
  • Laying paving: cutting curbstones and paving slabs to size
  • Construction work: cutting out openings in brick or concrete walls
