HDA-PF Undercut anchor

Undercut anchor HDA-PF M16x190/60 #339360

Configurator
Technical Data
Documents
Features & Applications
Related Products
9364.tif
HDA-PF, HDA-TF
HDA-PF, HDA-TF
HAD Design anchors

Ultimate-performance pre-set undercut anchor for dynamic loads (sherardised steel)

  • Material, corrosion: Carbon steel, HDG (hot-dip galvanised)/sherardised
  • Head configuration: Externally threaded
  • Max. fixture thickness at standard embedment depth: 60 mm

Choose options

Anchor size
  • M16
Standard embedment depth
  • 190 mm
Max. fixture thickness at standard embedment depth
  • 60 mm
Pack size
  • 4 pc
 Product options
Quantity
Packs
Total Pieces
4
You can not see your company prices

Please Log in or register to see your company prices.

Discounted net
£1,028.88
£257.22 / 1 Piece

Technical Data

Material, corrosion
Carbon steel, HDG (hot-dip galvanised)/sherardised
Head configuration
Externally threaded
Max. fixture thickness at standard embedment depth
60 mm
PROFIS software
No

Documents

Approval document
Technical information
Brochure
Sustainability Documentation
Operating Instruction
pdf BZS D 09-601 for HDA self-cutting undercut anchor, English [ 1 MB ]

Features & Applications

Features

  • Combines the advantages of a post-installed mechanical anchor, i.e. flexibility and immediate loading, with the performance of a cast-in-place headed stud
  • Close spacing and small edge distances thanks to very low expansion forces
  • Self-undercutting facilitates fast and reliable installation – no separate undercutting tool or handling needed
  • The resulting keying effect helps provides a secure hold even in cracked concrete
  • Manufactured under the NQA-1 nuclear quality assurance program

Applications

  • Safety-relevant, heavy-duty fastenings for dynamic loading in cracked or uncracked concrete, including applications in nuclear power plants
  • Examples: supports for heavy pipes, safety barriers, industrial machines, crane rails, dorm structures, crash barriers, roof fastening points, elevator tracks, bridge retrofitting etc.
