TE-CD (SDS Plus) Metric hammer drill bit
Ultimate SDS Plus (TE-C) hammer drill bit for virtually dust-free drilling in concrete
- Connection end: TE-C (SDS-plus)
- Base material: Reinforced concrete, Concrete
- Working mode: Hammer drilling
ultimate
Customers also searched for Drill Bit, hollow drill bit , dust removal or safe set.
Choose options
Diameter
- 12 mm
- 14 mm
- 16 mm
- 18 mm
Working length
- 200 mm
- 240 mm
Length
- 330 mm
- 370 mm
Pack size
- 1 pc
- 4 pc
Quantity
Packs
Total Pieces
1
Discounted net
From £78.70
Technical Data
Connection end
TE-C (SDS-plus)
Base material
Reinforced concrete, Concrete
Working mode
Hammer drilling
Head shape
Multi cutter
Head material composition
Tungsten carbide
Need vacuum cleaner
Yes
Product class
Ultimate
Documents
Features & Applications
Features
- Drilling and hole cleaning in one step
- Optimum hole cleaning for consistent anchor setting
- Robustness, lifetime and drilling speed equal to TE-YX drill bits
- Minimises snagging or sticking when drilling into rebar
Applications
- Drilling holes for anchoring structural steel connections (e.g. steel columns, beams)
- Drilling holes for structural connections with post-installed rebar
- Drilling holes for anchoring secondary steel structures (e.g. staircases, steel ledgers)
- Drilling holes for structural renovation or upgrading with post-installed rebar
- Drilling holes for substitution of misplaced or missing rebars
For approval or certificate information, please see individual items.
