Nuron

DD 160-22 Cordless core drill

L601333 (3531505)
L601340 (3531563)
L157496_cropped (5043083)
L157452_cropped (5043078)
L157451_cropped (5043074)
L150241_cropped (3582638)
L150250_cropped (3582644)

Compact and powerful cordless coring machine for rig-based diamond coring from 52-162 mm (2 – 6-3/8") in diameter (Nuron battery platform)

  • Diameter range: 50 - 162 mm
  • Base material: Asphalt, Concrete, Reinforced concrete
  • Operation mode: Rig-based drilling system

Customise your kit

Tool body
Tool body with case Includes: 1x Chuck BI+ (M27x1.5), 3x Clip DD 160-22 printed, 1x Tool case DD 110/150/160 assy
How many kits do you want to order?
You can not see your company prices

Please Log in or register to see your company prices.

Discounted net
£1,600.20

Technical Data

Diameter range
50 - 162 mm
Base material
Asphalt, Concrete, Reinforced concrete
Operation mode
Rig-based drilling system
Rated input power
1650 W
Weight according to EPTA-Procedure 01/2003 without battery
6.8 kg
Weight of complete system
19 kg
Dimensions (LxWxH)
444 x 162 x 182 mm
A-weighted emission sound pressure level
87 dB (A) 1
Corner accessibility
101 mm
  1. According to the applicable product standard (see the Operating Instruction for more details)

Documents

pdf Operating Instruction DD 160-22 (01), Danish, German, English, Spanish, Estonian, Finnish, French, Italian, Lithuanian, Latvian, Dutch, Norwegian, Portuguese, Swedish [ 6.5 MB ]
pdf Operating Instruction DD 160-22 (01), Bulgarian, Czech, Greek, English, Hebrew, Croatian, Hungarian, Polish, Romanian, Slovak, Slovenian, Serbian [ 6.5 MB ]
pdf Operating Instruction DD 160 (01), Arabic, Bulgarian, cn, Czech, Danish, German, Greek, English, Spanish, Estonian, Finnish, French, Croatian, Hungarian, Italian, Japanese, Korean, Lithuanian, Latvian, Dutch, Norwegian, Polish, Portuguese, Romanian, Russian, Slovak, Slovenian, Swedish, Turkish, Ukrainian, Chinese [ 14.9 MB ]
pdf Operating Instruction China RoHS II, cn, English, Chinese [ 5.6 MB ]
pdf Operating Instruction Taiwan RoHS DD 160, cn, English, Chinese [ 249.8 KB ]

Features & Applications

Features

  • Compact and easy to handle – our user-friendly core drill for rig-based coring is now cordless for even easier handling and mobility
  • E-gears for higher performance – electronic gears set RPM/torque combinations for optimised drilling speeds at every diameter
  • Multiple drill stand options – combine with our high-grade drill mean many useful features or our compact drill mean standard functions
  • More coring per charge – pair with new cordless optimised core bits for up to 30% more battery reach
  • Easier core removal – oscillating function helps shake loose stuck concrete cores to save downtime

Applications

  • Rig-based wet drilling in concrete for pipe penetrations in plumbing, heating and air conditioning installations
  • Rig-based wet drilling for small pipe penetrations in plumbing applications
  • Stitch drilling for cable trays and ventilation ducts
