X-HVB Shear connector

Configurator
Technical Data
Documents
Features & Applications
Related Products
X-HVB shear connector X-HVB Verbunddübel
X-HVB 40, Shear Connector (88547)
X-HVB 40, Shear Connector (88706)
X-HVB 110 (Shear Connector) X-HVB 110 (Verbund-Dübel)
X-HVB, DX 76 PTR
L105752_cropped (187880)
L105805_cropped (187882)
L105827_cropped (187887)
L105902_cropped (187889)
L105924_cropped (187891)
L105933_cropped (187893)
L105963_cropped (187895)
L105978_cropped (187897)
L105995_cropped (187901)
L106002_cropped (187903)
L106014_cropped (187905)
L106016_cropped (187907)

Shear connector for composite beam constructions

  • Application: Metal deck
  • For use with (tools): DX 76
  • Corrosion protection: Galvanised zinc coated <20 µm
ultimate

Customers also searched for sheer connectors, HVB or metal deck composite beam constructions.

Choose options

Height
  • 43 mm
  • 52 mm
  • 80 mm
  • 95 mm
  • 113 mm
  • 128 mm
  • 143 mm
Fastener shank length
  • 26 mm
Length
  • 60 mm
  • 63 mm
  • 88 mm
  • 99 mm
Pack size
  • 120 pc
  • 125 pc
  • 200 pc
  • 250 pc
 Product options
Quantity
Packs
Total Pieces
1
You can not see your company prices

Please Log in or register to see your company prices.

Discounted net
From £643.25

Technical Data

Application
Metal deck
For use with (tools)
DX 76
Corrosion protection
Galvanised zinc coated <20 µm
Environmental conditions
Dry indoor
Approvals
DIBt, SCI, SOCOTEC, TZUS
Base materials
Steel
Product class
Ultimate

Documents

Approval document
Technical information
Declaration of performance
Operating Instruction
pdf ETA-15/0876 for nail shear connector, German, English, French [ 8.4 MB ]
pdf UKTA-0836-22_6558_X-HVB [ 1 MB ]

Features & Applications

Features

  • Economical alternative to stud welding – no expensive equipment required
  • Portable solution which can be moved around the jobsite easily without the need for pulling electric cables
  • Ideal for renovating old buildings where welding on existing cast-iron beams can be problematic
  • Hilti web-based software available to aid optimum design in meeting the load requirements
  • Increased productivity – quick set-up and usable in all weather conditions

Applications

  • Holding concrete slabs to steel structures to resist shear forces and increase shear loading capacity in composite structures
  • Can be used on galvanised and painted beams

For approval or certificate information, please see individual items.
