3D Design plug-in suite
3D modeling plug-ins for planning mechanical, electrical and industrial designs in engineering software such as Intergraph, Aveva, Autodesk, and Bentley
- Graphic card requirements: OpenGL 3.0 support
- System requirements: As per host system
- Minimum disc space required: 1024 MB
Choose options
Licensing
- After sign up you will receive further instructions, including the software download link, sent out to your registered e-mail address
Pack size
- 1 pc
Quantity
Packs
Total Pieces
1
From £0.00
Technical Data
Graphic card requirements
OpenGL 3.0 support
System requirements
As per host system
Minimum disc space required
1024 MB
Security and authorizations
Hilti-signed software
Supported operating system
Windows 7
Features & Applications
Features
- Seamless integration with industry-standard engineering software
- Smart features throughout your workflow to unleash productivity
- Built-in intelligence to reduce errors
- Customizable fabrication drawings and automatically generated Bills of Material
- Expert support available every step of the way
Applications
- Integrate our plug-ins with your daily software (Intergraph Smart3D®, Aveva PDMS®, Aveva Everything3D®, Bentley MicroStation®, Bentley OpenPlant®, and Autodesk Plant3D®) and gain access to the entire Hilti digital catalog so you can create digital twins of your assets
- Deliver faster and more flexible designs through smart features such as: pre-built templates and typicals for faster modeling, design wizards for quickly selecting elements and performing tasks correctly, and flexible solutions to perform freeform designs (limited to some solutions)
- Reduce errors with built-in filters, rules, and validations to ensure build-ready final designs that are up to specification
- Deliver accurate fabrication drawings customized to meet construction team specifications and detailed BOM lists that even include items outside the 3D model (eg. Fasteners)
- Minimize downtime with the help of our plant design experts who will provide plug-in installations and upkeep, consultations on best solutions with your administrators, relevant portfolio library setup, troubleshooting, training services, and bespoke assemblies at a nominal fee for project libraries
